2 channel 2A(500AV) independent back dimming control output, dimming range 0-100%

Could compatible front or back dimming electronic transformer, or dimming LED driver.

Network device management, scene setting, and calls can be entirely operated in the machine through the LCD menu to complete.

The scene or group name of LCD dynamic display, can be as user-defined language or character

Manual fast switch, can turn on or off output quickly

Can preset 99 scenes, 16 special effects, 16 events at most, built-in chase, construction, gradual, transition, and other 38 kinds of lighting effects

Can set the channel delay time and gradually brighter time, effective protection for the light source

linear dimming output, dimming range 0-100%, and flicker-free dimming control the fluorescent, HID, and LED

LED status indicator, the standard color is red or green, can also choose other colors

Can be choose work at E-Lighting or AUTO（DMX512）model

1 programmable dry contact AUX input

Can be programmed above  E-Lighting Config Tools V1.0 edition

85-265V AC 50/60Hz single phase power supply, current<5A

Ta:-20---70°C max.

Dimension, 105x90x58mm,6P standard rail mounting
